When choosing colocation, many companies ask the same practical question: what rack sizes are available in a data center, and when does it make sense to consider options such as full rack colocation?
The size of a rack directly affects infrastructure planning, equipment density, power consumption, and future scalability. An error at the calculation stage can lead to a lack of space, cooling issues, or the need for premature expansion.
Let us examine which sizes are considered standard, how deployment formats differ, and how to choose the optimal option for your business.
The basic standard: what is a 19-inch rack
Almost all modern colocation data centers use the 19-inch standard.
19 inches refers to the width of the mounting area used for installing servers and networking equipment. This is not the total cabinet width, but the distance between the mounting rails.
This standard is used for:
- servers
- switches
- routers
- storage systems
- PDUs
Thanks to standardization, equipment from different manufacturers is compatible within the same rack.
What does U (rack unit) mean
The height of equipment in a rack is measured in units – U.
1U = 1.75 inches (44.45 mm). Most servers are available in:
- 1U
- 2U
- 4U
The total height of a rack is determined by the number of available rack units. The standard height calculation formula is:
1U = 1.75 inches
This unit of measurement defines the entire vertical capacity of a rack.
Standard height of colocation racks
The most common rack heights are:
- 42U – historical industry standard
- 45U – extended version
- 47U – commonly used in modern European data centers
- 48U – used in newly built facilities
For a long time, 42U was considered the industry benchmark. However, with increasing equipment density and higher cabinet designs, modern data centers are increasingly using 47U or 48U racks.
The taller the rack, the more equipment can be installed without renting additional floor space.
Rack width and depth
Although the mounting standard is 19 inches, the external cabinet width is larger.
Typical parameters:
Width:
- 600 mm
- 800 mm (for better cable management)
Depth:
- 1000 mm
- 1100 mm
- 1200 mm (for high-density servers)
Depth is especially important when deploying:
- blade servers
- GPU servers
- storage systems
Modern AI servers often require racks with a depth of at least 1200 mm.
Half rack vs full rack – what is the difference
In colocation, you rent space inside the cabinet rather than the cabinet itself.
- Full rack. An entire rack – for example, the full 42U or 47U.
- Half rack. Half of a rack – typically 20–24U.
- Quarter rack. Approximately 10U.
This approach allows businesses to scale gradually without overpaying for unused space.
Weight load and limitations
Rack size is not only about height.
It is important to consider:
- permitted floor load
- maximum weight per rack
- distribution of heavy equipment
The standard load capacity of a rack can range from 800 to 1500 kg. When deploying GPU servers or heavy storage arrays, it is essential to coordinate specifications with the data center operator in advance.
Power density: a key factor
Today, rack size is increasingly evaluated not in U, but in kilowatts.
Typical figures:
- 3–5 kW – traditional load
- 8–12 kW – increased density
- 20+ kW – high-density racks
Modern European data centers in Frankfurt often support 10–20 kW per rack, and specialized zones can handle even higher capacities. Therefore, when selecting a rack size, it is essential to consider not only physical space but also the power consumption of the equipment.
How to choose the right rack size
When planning, the following factors are considered:
- The number of servers and their height in U
- Scaling plans for the next 2–3 years
- Power consumption
- Cooling requirements
- Type of equipment (GPU, storage, networking)
If a project is designed for stable workloads and gradual growth, a half rack with the option to expand to a full rack is often the optimal choice. For large-scale projects with high density, it is more reasonable to lease a full rack in a high-power zone from the beginning.
European practice: why 47U and 48U are becoming more common
Modern data centers in Germany and the Netherlands are designed with a focus on:
- taller racks
- improved airflow
- support for high-density workloads
- AI and HPC infrastructure
As a result, the industry standard is gradually shifting from 42U to 47–48U.
This allows for more efficient use of data center space and reduces the cost per rack unit.
Why rack selection affects scalability and costs
Colocation racks have a standardized width of 19 inches and a height ranging from 42U to 48U. However, choosing the optimal size depends not only on the number of servers, but also on:
- power capacity
- equipment depth
- weight
- scaling plans
In modern European infrastructure, a rack is not just a metal cabinet, but an element of engineering strategy that affects efficiency, cooling performance, and long-term total cost of ownership.
